Thermostat 143F 62C for Johnson Evinrude 60-300 HP V4 V8 Outboard 0329766
Thermostat 143F 62C for Johnson Evinrude 60-300 HP V4 V8 Outboard 0329766
Product Overview
143 °F / 62 °C thermostat for Johnson and Evinrude outboards from 60 HP to 300 HP, replacing 0329766, 0394409, 0434137 and 0765580, and crossing to Sierra 18-3500 and GLM 13170. One thermostat is supplied.
This is the thermostat used in the V4 and V8 gearcase cooled motors, the loopcharged and crossflow blocks from the 1980s and early 1990s. Sixty two degrees Celsius is a cold rating; these motors are meant to run cool and a hotter thermostat will not improve them.
A thermostat stuck open makes the motor run cold, foul plugs and drink fuel. Stuck shut, it cooks the powerhead. If the head is hot to touch within two minutes on muffs and the telltale is weak, stop and check the thermostat and the impeller together.
Specifications & Attributes
| Specification | Detail |
|---|---|
| Condition | New / New with tags |
| Type | Outboard thermostat |
| Opening Temperature | 143 °F |
| Opening Temperature | 62 °C |
| Application | Johnson and Evinrude V4 and V8 outboards |
| Country of Origin | Taiwan |
OEM Cross Reference
| Brand | OEM Part Numbers |
|---|---|
| Johnson / Evinrude | 0329766, 0394409 |
| Johnson / Evinrude | 0434137, 0765580 |
| Sierra | 18-3500 |
| GLM | 13170 |
Compatible Engines
| Horsepower | Configuration | Years |
|---|---|---|
| 60 HP | V4 | 1989 to 1992 |
| 65 HP | V4 | 1987 to 1992 |
| 70 HP | V4 | 1986 to 1992 |
| 85 HP | V8 | As listed |
| 120 HP | V8 | 1985 to 1993 |
| 125 HP | V8 | 1989 to 1993 |
| 140 HP | V8 | 1985 to 1993 |
| 185 HP | V8 | 1989 to 1992 |
| 200 HP | V8 | 1986 to 1992 |
| 225 HP | V8 | 1986 to 1992 |
| 250 HP | V8 | 1991 to 1993 |
| 275 HP | V8 | 1985 to 1988 |
| 300 HP | V8 | 1985 to 1993 |
What's Included
| Component | Qty |
|---|---|
| Thermostat | 1 |
Condition & Warranty
| Item | Detail |
|---|---|
| Condition | New / New with tags |
| Warranty | Standard |
| Packaging | Sealed retail packaging |
Before You Buy
- Check the number on the old thermostat, the four stroke motors use a different rating
- Check the housing for corrosion pitting where the thermostat seats
- Check the impeller at the same service, a thermostat is often changed because the impeller failed
- Fit the thermostat the right way round, the spring end goes toward the hot side of the housing
- Run on muffs and watch the head temperature rise and then hold steady
- Check the telltale and recheck for leaks around the cover after the first run
